A Digital Noah’s Ark: How UrBackup and TrueNAS Protect Your Data

In today’s digital world, our lives—both personal and professional—are recorded as data. From family photos to crucial company databases, losing this information can be catastrophic. Despite this, many individuals and businesses still treat backups as an afterthought. Here is a complete guide to building a powerful, automated, and secure backup system using free tools: UrBackup, TrueNAS Scale, and Tailscale.

Why You Need a Plan B: The Importance of Backups

Imagine one morning your laptop’s hard drive refuses to work. Or the server that runs your business falls victim to a ransomware attack, and all your files are encrypted. These aren’t scenarios from science-fiction films but everyday reality. Hardware failure, human error, malicious software, or even theft—the threats are numerous.

A backup is your insurance policy. It’s the only way to quickly and painlessly recover valuable data in the event of a disaster, minimising downtime and financial loss. Without it, rebuilding lost information is often impossible or astronomically expensive.

The Golden Rule: The 3-2-1 Strategy

In the world of data security, there is a simple but incredibly effective principle known as the 3-2-1 strategy. It states that you should have:

• THREE copies of your data (the original and two backups).
• On TWO different storage media (e.g., a disk in your computer and a disk in a NAS server).
• ONE copy in a different location (off-site), in case of fire, flood, or theft at your main location.

Having three copies of your data drastically reduces the risk of losing them all simultaneously. If one drive fails, you have a second. If the entire office is destroyed, you have a copy in the cloud or at home.

A Common Misconception: Why RAID is NOT a Backup

Many NAS server users mistakenly believe that a RAID configuration absolves them of the responsibility to make backups. This is a dangerous error.

RAID (Redundant Array of Independent Disks) is a technology that provides redundancy and high availability, not data security. It protects against the physical failure of a hard drive. Depending on the configuration (e.g., RAID 1, RAID 5, RAID 6, or their RAID-Z equivalents in TrueNAS), the array can survive the failure of one or even two drives at the same time, allowing them to be replaced without data loss or system downtime.

However, RAID will not protect you from:

• Human error: Accidentally deleting a file is instantly replicated across all drives in the array.
• Ransomware attack: Encrypted files are immediately synchronised across all drives.
• Power failure or RAID controller failure: This can lead to the corruption of the entire array.
• Theft or natural disaster: Losing the entire device means losing all the data.

Remember: Redundancy protects against hardware failure; a backup protects against data loss.

Your Backup Hub: UrBackup on TrueNAS Scale

Creating a robust backup system doesn’t have to involve expensive subscriptions. An ideal solution is to combine the TrueNAS Scale operating system with the UrBackup application.

• TrueNAS Scale: A powerful, free operating system for building NAS servers. It is based on Linux and offers advanced features such as the ZFS file system and support for containerised applications.
• UrBackup: An open-source, client-server software for creating backups. It is extremely efficient and flexible, allowing for the backup of both individual files and entire disk images.

The TrueNAS Protective Shield: ZFS Snapshots

One of the most powerful features of TrueNAS, resulting from its use of the ZFS file system, is snapshots. A snapshot is an instantly created, read-only image of the entire file system at a specific moment. It works like freezing your data in time.

Why is this so important in the context of ransomware?

When ransomware attacks and encrypts files on a network share, these changes affect the “live” version of the data. However, previously taken snapshots remain untouched and unchanged because they are inherently read-only. In the event of an attack, you can restore the entire dataset to its pre-infection state in seconds, completely nullifying the effects of the attack.

You can configure TrueNAS to automatically create snapshots (e.g., every hour) and retain them for a specified period. This creates an additional, incredibly powerful layer of protection that perfectly complements the backups performed by UrBackup.

Advantages and Disadvantages of the Solution

Advantages:

• Full control and privacy: Your data is stored on your own hardware.
• No licence fees: The software is completely free.
• Exceptional efficiency: Incremental backups save space and time.
• Flexibility: Supports Windows, macOS, Linux, physical servers, and VPS.
• Disk image backups: Ability to perform a “bare-metal restore” of an entire system.

Disadvantages:

• Requires your own hardware: You need to have a NAS server.
• Initial configuration: Requires some technical knowledge.
• Full responsibility: The user is responsible for the security and operation of the server.

Step-by-Step: Installation and Configuration

1. Installing UrBackup on TrueNAS Scale

1. Log in to the TrueNAS web interface.
2. Navigate to the Apps section.
3. Search for the UrBackup application and click Install.
4. In the most important configuration step, you must specify the path where backups will be stored (e.g., /mnt/YourPool/backups).
5. After the installation is complete, start the application and go to its web interface.

2. Basic Server Configuration

In the UrBackup interface, go to Settings. The most important initial options are:

• Path to backup storage: This should already be set during installation.
• Backup intervals: Set how often incremental backups (e.g., every few hours) and full backups (e.g., every few weeks) should be performed.
• Email settings: Configure email notifications to receive reports on the status of your backups.

3. Installing the Client on Computers

The process of adding a computer to the backup system consists of two stages: registering it on the server and installing the software on the client machine.

a) Adding a new client on the server:

1. In the UrBackup interface, go to the Status tab.
2. Click the blue + Add new client button.
3. Select the option Add new internet/active client. This is recommended as it works both on the local network and over the internet (e.g., via Tailscale).
4. Enter a unique name for the new client (e.g., “Annas-Laptop” or “Web-Server”) and click Add client.

b) Installing the software on the client machine:

1. After adding the client on the server, while still on the Status tab, you will see buttons to Download client for Windows and Download client for Linux.
2. Click the appropriate button and select the name of the client you just added from the drop-down list.
3. Download the prepared installation file (.exe or .sh). It is already fully configured to connect to your server.
4. Run the installer on the client computer and follow the instructions.

After a few minutes, the new client should connect to the server and appear on the list with an “Online” status, ready for its first backup.

Security Above All: Tailscale Enters the Scene

How can you securely back up computers located outside your local network? The ideal solution is Tailscale. It creates a secure, private network (a mesh VPN) between all your devices, regardless of their location.

Why use Tailscale with UrBackup?

• Simplicity: Installation and configuration take minutes.
• “Zero Trust” Security: Every connection is end-to-end encrypted.
• Stable IP Addresses: Each device receives a static IP address from the 100.x.x.x range, which does not change even when the device moves to a different physical location.

What to do if the IP address changes?

If for some reason you need to change the IP address of the UrBackup server (e.g., after switching from another VPN to Tailscale), the procedure is simple:

1. Update the address on the UrBackup server: In Settings -> Internet/Active Clients, enter the new, correct server address (e.g., urbackup://100.x.x.x).
2. Download the updated installer: On the Status tab, click Download client, select the offline client from the list, and download a new installation script for it.
3. Run the installer on the client: Running the new installer will automatically update the configuration on the client machine.

Managing and Monitoring Backups

The UrBackup interface provides all the necessary tools to supervise the system.

• Status: The main dashboard showing a list of all clients, their online/offline status, and the status of their last backup.
• Activities: A live view of currently running operations, such as file indexing or data transfer.
• Backups: A list of all completed backups for each client, with the ability to browse and restore files.
• Logs: A detailed record of all events, errors, and warnings—an invaluable tool for diagnosing problems.
• Statistics: Charts and tables showing disk space usage by individual clients over time.

Backing Up Databases: Do It Right!

Never back up a database by simply copying its files from the disk while the service is running! This risks creating an inconsistent copy that will be useless. The correct method is to perform a “dump” using tools like mysqldump or mariadb-dump.

Method 1: All Databases to a Single File

A simple approach, ideal for small environments.

Command: mysqldump –all-databases -u [user] -p[password] > /path/to/backup/all_databases.sql

Method 2: Each Database to a Separate File (Recommended)

A more flexible solution. The script below will automatically save each database to a separate, compressed file. It should be run periodically (e.g., via cron) just before the scheduled backup by UrBackup.

#!/bin/bash

# Configuration
BACKUP_DIR="/var/backups/mysql"
DB_USER="root"
DB_PASS="YourSuperSecretPassword"

# Check if user and password are provided
if [ -z "$DB_USER" ] || [ -z "$DB_PASS" ]; then
    echo "Error: DB_USER or DB_PASS variables are not set in the script."
    exit 1
fi

# Create backup directory if it doesn't exist
mkdir -p "$BACKUP_DIR"

# Get a list of all databases, excluding system databases
DATABASES=$(mysql -u "$DB_USER" -p"$DB_PASS" -e "SHOW DATABASES;" | tr -d " " | grep -vE "(Database|information_schema|performance_schema|mysql|sys)")

# Loop through each database
for db in $DATABASES; do
    echo "Dumping database: $db"
    # Perform the dump and compress on the fly
    mysqldump -u "$DB_USER" -p"$DB_PASS" --databases "$db" | gzip > "$BACKUP_DIR/$db-$(date +%Y-%m-%d).sql.gz"
    if [ $? -eq 0 ]; then
        echo "Dump of database $db completed successfully."
    else
        echo "Error during dump of database $db."
    fi
done

# Optional: Remove old backups (older than 7 days)
find "$BACKUP_DIR" -type f -name "*.sql.gz" -mtime +7 -exec rm {} \;

echo "Backup process for all databases has finished."

Your Digital Fortress

Having a solid, automated backup strategy is not a luxury but an absolute necessity. Combining the power of TrueNAS Scale with its ZFS snapshots, the flexibility of UrBackup, and the security of Tailscale allows you to build a multi-layered, enterprise-class defence system at zero software cost.

It is an investment of time that provides priceless peace of mind. Remember, however, that no system is entirely maintenance-free. Regularly monitoring logs, checking email reports, and, most importantly, periodically performing test restores of your files are the final, crucial elements that turn a good backup system into an impregnable fortress protecting your most valuable asset—your data.
