Secure Home Directory Backup to TrueNAS Using Duplicati and Docker

Andrzej Majewski Written in Docker EN, Linux EN, Operating System, Serwer www, TrueNAS EN

Linux devotee and Bournemouth-based IT expert, obsessed with homelabbing, server performance, and elegant Python code.

Table of Contents

Toggle

Creating a reliable backup is absolutely critical, especially when working with code (PHP, Python, JavaScript) or managing essential systems, such as an ERP system. A local backup is simply not enough – we need a remote, encrypted solution that is resilient to drive failure.

Duplicati, combined with Docker and a TrueNAS server (utilising SFTP), offers a gold standard solution. While the setup can be tricky, this guide will help you avoid the common pitfalls related to dependencies (libicu) and permissions (Access Denied) that we encountered.

1. Prerequisites and Architecture

We will install Duplicati inside a Docker container on the client machine (your Ubuntu system), and securely transfer the data to the TrueNAS server using the SFTP (SSH) protocol.

Prerequisites:

1. Docker installed and configured on your Ubuntu machine.
2. SSH Service enabled on TrueNAS.
3. A destination folder created on TrueNAS (e.g., /mnt/Your_Pool/Duplicati) with write permissions for your SSH user.

2. Launching the Duplicati Container (The Reliable Version)

We will use the popular linuxserver/duplicati image. To prevent start-up failures and permission issues, we must correctly define the volume mappings and environment passwords.

Preparing the Directory and User

Before running the container, ensure your configuration directory exists. The PUID and PGID variables guarantee that Duplicati has full access to your home directory.

# Check your UID and GID (usually 1000)
UID=$(id -u andre)
GID=$(id -g andre)

# Create the directory to store Duplicati's configuration files
mkdir -p /home/andre/duplicati_config

The Docker Run Command

We must use essential environment keys (for launch and web interface password) and two volume mappings (config and source files).

Important: Use your own, strong values for SETTINGS_ENCRYPTION_KEY and DUPLICATI__WEBSERVICE_PASSWORD.

docker run -d \
  --name=duplicati \
  -p 8200:8200 \
  -e PUID=$UID \
  -e PGID=$GID \
  -e SETTINGS_ENCRYPTION_KEY="YOUR_UNIQUE_CONFIG_ENCRYPTION_KEY" \
  -e DUPLICATI__WEBSERVICE_PASSWORD="YOUR_GUI_INTERFACE_PASSWORD" \
  -v /home/andre/duplicati_config:/config \
  -v /home/andre:/source/home/andre \
  --restart unless-stopped \
  linuxserver/duplicati:latest

• /config: Persistent storage for the Duplicati database and settings.
• /source/home/andre: Maps your entire home directory (the source) into the container.
• PUID/PGID: Maps the container process to your user’s UID/GID (andre) to prevent Access Denied errors when backing up your home folder.

3. Configuring the Backup to TrueNAS

Once the container is running successfully (check docker ps), open your browser.

Step 1: Accessing the Interface

Navigate to: http://localhost:8200

Log in using the password you defined in the DUPLICATI__WEBSERVICE_PASSWORD environment variable.

Step 2: Setting the Remote Repository (Destination)

1. Click Add backup and proceed to the Destination (2) step.
2. Storage Type: Select SFTP (SSH).
3. Server: Enter your TrueNAS IP address (e.g., 192.168.0.13).
4. Path on server: Enter the full path to your TrueNAS dataset, e.g., /mnt/Your_Pool/Duplicati.
5. Username/Password: Provide the login details for your SSH user (e.g., andre) on TrueNAS.
6. Click Test connection — you must see the Connection worked! message.

Step 3: Selecting Source Data

In the Source Data (3) step, you will select the folders you mapped into Docker:

1. In the file tree, locate and select the /source/home/andre folder.
2. Select the critical sub-folders (e.g., Documents, Projects, SSH Keys in .ssh).

Filters (Crucial for Efficiency): To avoid backing up redundant data (which led to previous issues), add these exclusion rules in the Filters section:

Step 4: Setting Options (Retention)

In the Options (5) section, set:

• Remote volume size: 50 MB (or 100 MB).
• Backup retention: Smart backup retention (The best policy for managing space).

Upon saving, Duplicati will begin creating encrypted, deduplicated, and automatic backups, securing your development environment and data against local drive failure.
